Electrofusion Processors
240V
120V
Features
Unit electronics are gasket sealed - no air venting means no risk of damage due to dust or debris contamination
Storage of up to 15,000 fusions
USB interface for data download and calibration
Includes 4.0mm and 4.7mm output cable pin adapters
Heavy-duty transformer will not overheat
SmartScan GPS option available
Designed and built in the U.S.A.
All service and repairs are performed in the U.S.A. by the same technicians that build them
3-year extended calibration period
1-year manufacturer’s limited warranty
Heavy-duty
polyurethane
wheels
with
stainless steel
bearings
90° non-rotating
output
cable pin
adapters
Industrial grade
NEMA
locking
plug
Gasket sealed
12 ft (3.7m)
input and output
cables
Details
Strongbridge electrofusion processors are capable of fusing all universally barcoded electrofusion fittings available in the market today. Fusions are made easy with our intuitive user interface, SmartScan barcode scanner and simplified step-by-step process. Strongbridge processors can also be operated in two additional manual input modes for maximum flexibility.
All fusion data is stored internally and can easily be downloaded to an external USB storage device or to a computer via the EF Utilities software (see below). Up to 37 points of data can be captured per fusion, including fusion voltage and time, ambient temperature, current, operator identifier, and much more.
Our 240V processor is capable of fusing all sizes of electrofusion fittings at voltages ranging from 8 to 48 volts, while our 120V processor is capable of fusing fittings up to 24” at voltages ranging from 8 to 48 volts.
Software & Apps
Fusion data from Strongbridge electrofusion processors can be downloaded to an external USB storage device or directly to a computer via USB using a standard USB A to B cable and EF Technologies' Windows desktop software. For models equipped with Bluetooth, fusion data can also be accessed using EF Technologies' Android or Apple apps.
For full instructions on how to use the our app or desktop software, download our User Guide by Clicking Here
⚠️ Important: Before using any of these tools, you must first set up an account with EF Technologies, the developers of the software.
To create or update an account, please contact EF Technologies directly:
Phone: 302-451-1088 | Email: service@eft-inc.com
When setting up a new account, please include:
Preferred username (or we will default to your email address)
Preferred password (or we will assign a generic one)
Email address to link to the account
Serial number(s) of your fusion machine(s)
To download the software or apps, use the links below
